FRAME

2022 Meta HT AM - 29''/27'' on S / M & 29''/29'' on L / XL
Alloy 6061, triple butted tubes, T4, T6.

SHOCK

FORK

ROCKSHOX Yari RC, 150 mm travel
29", Motion Control damper, DebonAir, rebound, Boost (15 x 110 mm), 42 mm offset, 2 Tokens

HEADSET

ACROS ZS44 / ZS56
Alloy cups, sealed bearings

STEM

RIDE ALPHA Freeride 40
40 mm extension, 31,8 mm

HANDLEBAR

RIDE ALPHA R20 on S - RIDE ALPHA R27 on M / L / XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

GRIPS

ODI Elite Motion
Soft pro compound, single clamp, black

BRAKES

SRAM Guide T, 4 pistons, MatchMaker compatible
Rotors: SRAM G2 CleanSweep 200 / 180 mm, 6-bolt

SHIFTERS

SRAM NX Eagle
12s

CHAIN GUIDE

REAR DERAILLEUR

SRAM NX Eagle
12s

BOTTOM BRACKET

SRAM BSA
Threaded

CRANKSET

SRAM X1 1000 Eagle, 170 mm crank arms, DUB, Boost
Chainring: SRAM X1 1000 Eagle, 32t, Narrow-Wide

CHAIN

SRAM NX Eagle
12s

CASSETTE

SRAM PG-1210
12s, 11-50t

RIMS

SPANK Spike Race 33
Rear: 27.5'', 32h, 28 mm inner width on S / M - 29'', 32h, 28 mm inner width on L / XL - Front: 29'', 32h, 28 mm inner width on S / M / L / XL

HUBS

Rear: FORMULA DC-348A - Front: FORMULA DC-711
Rear: 32h, sealed bearings, 12 x 148 mm, Shimano Hyperglide - Front: 32h, sealed bearings, 15 x 110 mm

SPOKES/NIPPLES

SAPIM Leader
J-Bend 2.0 mm, stainless, with Nylok, black

TYRES

Rear: MAXXIS Dissector - Front: MAXXIS Dissector
Rear: 27.5'' x 2.6'', 3C MaxxTerra, EXO+, Tubeless Ready on S / M - 29'' x 2.6'', 3C MaxxTerra, EXO+, Tubeless Ready on L / XL - Front: 29" x 2.6", 3C MaxxTerra, EXO+, Tubeless Ready on S / M / L / XL

SEAT POST

KS Rage-I
31.6 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote

SADDLE

FIZIK Terra Alpaca X5
145 mm width, S-alloy rails

WEIGHT

14,2 kg / 31.30 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED

No

COLOUR

Keswick Green
Shiny Finish
