FRAME

2022 Meta HT AM - 29''/27'' on S / M & 29''/29'' on L / XL

Alloy 6061, triple butted tubes, T4, T6.

FORK

FOX 36 Performance, 150 mm travel

29", Fit Grip damper, 3 positions, rebound, Boost (15 x 110 mm), 44 mm offset, 2 Tokens

HEADSET

ACROS ZS44 / ZS56

Alloy cups, sealed bearings

STEM

RIDE ALPHA Freeride 40

40 mm extension, 31,8 mm

HANDLEBAR

RIDE ALPHA R20 on S - RIDE ALPHA R27 on M / L / XL

31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

GRIPS

ODI Elite Motion

Soft pro compound, single clamp, black

BRAKES

SHIMANO SLX, 2 pistons, I-Spec EV compatible

Rotors : SHIMANO SM-RT66 203 / 180 mm, 6-bolt

SHIFTERS

SHIMANO SLX

12s, RapidFire Plus

CHAIN GUIDE

-

REAR DERAILLEUR

SHIMANO SLX

12s

BOTTOM BRACKET

SHIMANO SLX

BSA, threaded

CRANKSET

SHIMANO SLX, 170 mm crank arms, Boost

Chainring: SHIMANO SLX, 32t

CHAIN

KMC X12

12s

CASSETTE

SHIMANO Deore

12s, 10-51t

RIMS

SPANK Spike Race 33

Rear: 27.5'', 32h, 28 mm inner width on S / M - 29'', 32h, 28 mm inner width on L / XL - Front: 29'', 32h, 28 mm inner width on S / M / L / XL

HUBS

Rear: FORMULA MSL-148A - Front: FORMULA DC-711

Rear: 32h, sealed bearings, 12 x 148 mm, SHIMANO Microspline - Front: 32h, sealed bearings, 15 x 110 mm

SPOKES/NIPPLES

SAPIM Race

J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black

TYRES

Rear: MAXXIS Dissector - Front: MAXXIS Dissector

REAR: 27.5'' x 2.6'', 3C MaxxTerra, New EXO+, Tubeless Ready on S / M - 29'' x 2.6'', 3C MaxxTerra, New EXO+, Tubeless Ready on L / XL - FRONT: 29" x 2.6", 3C MaxxTerra, New EXO+, Tubeless Ready on S / M / L / XL

SEAT POST

KS Rage-I

31.6 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote

SADDLE

FIZIK Terra Alpaca X5

145 mm width, S-alloy rails

WEIGHT

14,2 kg / 31.30 lb

Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED

No
