FRAME

CLASH, 170 mm travel
27.5'', Alloy 6069, triple butted tubes, T4, T6. Enduro bearings

SHOCK

OHLINS TTX22 M.2 Coil
230 x 65 mm, HSC, LSC, rebound, climb mode. Spring rates: 320lbs on S, 343lbs on M, 411lbs on L, 457lbs on XL

FORK

OHLINS RXF36 m.2 Air, 180 mm travel
27.5", TTX 18 damper, Ramp Up chamber, LSC, HSC, rebound, Boost (15 x 110 mm), 38 mm offset

HEADSET

ACROS ZS44/ZS56
Alloy cups, sealed bearings

STEM

RIDE ALPHA Freeride 40
40 mm extension, 31.8 mm

HANDLEBAR

RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

GRIPS

ODI Elite Motion
Soft pro compound, single clamp, black

BRAKES

SHIMANO XT, 4 pistons, I-Spec EV compatible
Rotors: Delivered with Shimano or Galfer discs, 203 mm, 6 bolts

SHIFTERS

SHIMANO XT
12s

CHAIN GUIDE

-

REAR DERAILLEUR

SHIMANO XT
12s

BOTTOM BRACKET

SHIMANO BBMT800
Pressfit

CRANKSET

SHIMANO XT, 170 mm crank arms, Boost
Chainring: SHIMANO XT, 34t, Dynamic Chain Engagement + Technology

CHAIN

SHIMANO XT
12s

CASSETTE

SHIMANO XT
12s, 10 - 51t

RIMS

DT SWISS EX511
27.5'', 28h, 30 mm inner width

HUBS

Rear: DT SWISS 350 - Front: DT SWISS 350
Rear: 28h, sealed bearings, 12 x 148 mm, Microspline Driver, 36t ratchet, black - Front: 28h, sealed bearings, 15 x 110 mm, black

SPOKES/NIPPLES

DT SWISS Competition
J-Bend, 2.0-1.8-2.0 mm, double butted, stainless, with Nylok, black

TYRES

Rear: SCHWALBE Big Betty - Front: SCHWALBE Magic Mary
Rear: 27.5" x 2.4", Super Trail, Addix Soft - Front: 27.5" x 2.4", Super Trail, Addix Soft

SEAT POST

KS Lev Integra
34.9 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L, 200 mm on XL, SouthPaw alloy remote

SADDLE

SDG Bel Air V3 Atmos
140 mm width, Lux-Alloy Rails

WEIGHT

15,5 kg / 34.17 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED

No
