FRAME

FRS, 200 mm travel

27.5'', Alloy 6069, triple butted tubes, T4, T6.

SHOCK

ROCKSHOX VIVID Coil Ultimate DH

250 x 75 mm, R damper, rebound

Spring rates: 300 lbs on S, 350 lbs on M, 400 lbs on L, 450 lbs on XL

FORK

ROCKSHOX BOXXER Ultimate

27.5", Charger 3.2 RC damper, DebonAir +, Linear XL, rebound, LSC, 20 x 110 mm thru-axle, 48 mm offset, 0 Token

HEADSET

ACROS ZS44 / ZS56

Alloy cups, sealed bearings

STEM

RIDE ALPHA DH 40

40 mm extension, direct mount, 31.8 mm

HANDLEBAR

RIDE ALPHA R27 on S - RIDE ALPHA R35 on M / L  / XL

31.8 mm, 760 mm width, 27 mm rise, Alloy 7075 on S - 31.8 mm, 780 mm width, 35 mm rise, Alloy 7075 on M / L - 31.8 mm, 800 mm width, 35 mm rise, Alloy 7075 on XL

GRIPS

RIDE ALPHA Mushroom

132 mm, single clamp, black

BRAKES

SRAM Maven Base, 4 pistons, sintered pads

Rotors : SRAM HS2 200 mm, 6-bolts

SHIFTERS

SRAM GX DH

7s

CHAIN GUIDE

E13 Vario

34-36t

REAR DERAILLEUR

SRAM GX DH

7s

BOTTOM BRACKET

SHIMANO MT800

BB107, pressfit

CRANKSET

E13 Helix Core GR, 160 mm crank arms

Chainring : E13 Helix Plus, 34t

CHAIN

KMC X11EL

11s, black

CASSETTE

SRAM PG-720 DH

7s, 11-25t

RIMS

DT SWISS F1900 Classic

27.5'', 32h, 30 mm inner width

HUBS

DT SWISS 370 Classic LN

Rear : 32h, sealed bearings, 12 x 150 mm, 18t ratchet,  Hyperglide - Front : 32h, sealed bearings, 20 x 110 mm

SPOKES/NIPPLES

DT SWISS Competition

J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with ProLock, black

TYRES

Rear : SCHWALBE Tacky Chan - Front : SCHWALBE Magic Mary

27.5"x2.50, Gravity, Soft, TR

SEAT POST

RIDE ALPHA

31.6 mm, 250 mm length

SADDLE

BURGTEC The Cloud Boost

S-Alloy rails, black

WEIGHT

17,35 kg / 38.25 lb

Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED

No
