FRAME

CLASH, 170 mm travel
27.5'', Alloy 6069, triple butted tubes, T4, T6. Enduro bearings

SHOCK

ROCKSHOX Super Deluxe Ultimate
230 x 65 mm, RCT damper, DebonAir, LSC, rebound, 2-position adjustment, HSC, 3 Tokens

FORK

ROCKSHOX Zeb Ultimate, 180 mm travel
27.5", Charger 2.1 RC2 damper, Debonair, LSC, HSC, rebound, Boost (15 x 110 mm), 38 mm offset, 0 Token

HEADSET

ACROS ZS44/ZS56
Alloy cups, sealed bearings

STEM

RIDE ALPHA Freeride 40
40 mm extension, 31.8 mm

HANDLEBAR

RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

GRIPS

ODI Elite Motion
Soft pro compound, single clamp, black

BRAKES

TRP DH-R Evo, 4 pistons
Rotors: TRP R1 203 mm, 6-bolt, 2.3 mm width

SHIFTERS

SRAM GX Eagle
12s

REAR DERAILLEUR

SRAM GX Eagle
12s

BOTTOM BRACKET

SRAM DUB
Pressfit

CRANKSET

SRAM GX Eagle, 170 mm crank arms, DUB, Boost
Chainring: SRAM GX Eagle, 34t, Narrow-Wide

CHAIN

SRAM GX Eagle
12s

CASSETTE

SRAM PG-1275
12s, 10 - 52t

RIMS

DT SWISS EX511
27.5'', 28h, 30 mm inner width

HUBS

Rear: DT SWISS 350 - Front: DT SWISS 350
Rear: 28h, sealed bearings, 12 x 148 mm, XD Driver, 36t ratchet, black - Front: 28h, sealed bearings, 15 x 110 mm, black

SPOKES/NIPPLES

DT SWISS Competition
J-Bend, 2.0-1.8-2.0 mm, double butted, stainless, with Nylok, black

TYRES

Rear: MAXXIS DHR II - Front: MAXXIS Assegai
Rear: 27.5" x 2.4", WT, 3C MaxxTerra, EXO+, Tubeless Ready - Front: 27.5" x 2.5", WT, 3C MaxxGrip, EXO+, Tubeless Ready

SEAT POST

KS Lev Integra
34.9 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L, 200 mm on XL, SouthPaw alloy remote

SADDLE

SDG Bel Air V3 Atmos
140 mm width, Lux-Alloy Rails

WEIGHT

15,5 kg / 34.17 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED

No
