FRAME

CLASH, 170 mm travel
27.5'', Alloy 6069, triple butted tubes, T4, T6. Enduro bearings

SHOCK

FOX DHX2 Factory
230 x 65 mm, HSC, LSC, HSR, LSR. 2-position (open / firm) lever. Spring rates : 400lbs on S, 450lbs on M, 500lbs on L, 550lbs on XL.

FORK

FOX 38 Factory, 180 mm travel
27.5", Grip 2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 37 mm offset, 1 spacer

HEADSET

ACROS ZS44/ZS56
Alloy cups, sealed bearings

STEM

TITLE ST1 35
40 mm extension, 35 mm, Alloy 6061 T6, oil slick stainless steel bolts

HANDLEBAR

TITLE AH1 35
35 mm, 810 mm width, 20 mm rise, Alloy 7050 T74

GRIPS

ODI Elite Motion
Soft pro compound, single clamp, black

BRAKES

SHIMANO XT, 4 PISTONS, I-SPECS EV COMPATIBLE OR TRP DH-R EVO, 4 PISTONS
Rotors: SHIMANO SM-RT86 203 mm, 6-bolt, Ice Technology Freeza or TRP R1 203mm, 6-bolt, 2.3 mm

SHIFTERS

SRAM GX DH
7s

CHAIN GUIDE

E13 TRS
30 - 32t

REAR DERAILLEUR

SRAM GX DH
7s

BOTTOM BRACKET

SRAM DUB
Pressfit

CRANKSET

TRUVATIV Descendant, 165 mm crank arms, DUB
Chainring: TRUVATIV Descendant  X-Sync, 32t

CHAIN

KMC X11EL
Black

CASSETTE

SRAM GX DH
7s, 11 - 25t

RIMS

SPANK Spike Race 33
27.5'', 32h, 28 mm inner width, Tubeless Ready

HUBS

Rear: SPANK Spike - Front: SPANK Spike
Rear: HEX J-Type, 32h, 2 sealed bearings, 12 x 148 mm, XD, black - Front: HEX J-Type, 32h, 2 sealed bearings, 15 x 110 mm, black

SPOKES/NIPPLES

SPANK J-Hook
J-Bend, tripple butted 2.2/1.8/2.0, stainless, with Nylok, black

TYRES

Rear: MAXXIS DHR II - Front: MAXXIS Assegai
Rear: 27.5" x 2.4", WT, 3C MaxxTerra, Double Down, Tubeless Ready - Front: 27.5" x 2.5", WT, 3C MaxxGrip, Double Down, Tubeless Ready

SEAT POST

SDG Micro I-Beam
31.6 mm, 250 mm length

SADDLE

SDG Patriot I-Beam
31.6 mm, 250 mm length, diameter reducer

WEIGHT

15,6 kg / 34.39 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED

No
