FRAME

CLASH, 170 mm travel
27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings

SHOCK

ROCKSHOX Deluxe Select
230 x 65 mm, R damper, rebound

FORK

MARZOCCHI Bomber Z1
27.5'', RAIL 2.0, Sweep-Adj, rebound, Boost (15 x 110 mm), 3 pos, 44 mm offset, 0 token

HEADSET

ACROS ZS44 / ZS56
Alloy cups, sealed bearings

STEM

RIDE ALPHA 40
40 mm extension, 31.8 mm

HANDLEBAR

RIDE ALPHA R27
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

GRIPS

RIDE ALPHA Mushroom
Ultra-soft compound, single clamp, black

BRAKES

SRAM DB4, 4 pistons, resin pads
Rotors: SRAM G2 200 mm, 6-bolt, 2.0 mm thickness

SHIFTERS

SHIMANO Deore
12s

REAR DERAILLEUR

SHIMANO Deore
12s

BOTTOM BRACKET

SHIMANO SM-BB-71
Pressfit

CRANKSET

SHIMANO MT512, 165 mm crank arms
Chainring: SHIMANO MT512, 32t

CHAIN

SHIMANO Deore
12s

CASSETTE

SHIMANO Deore
12s, 10-51t

RIMS

DT SWISS E593
27.5'', 32h, 30 mm inner width

HUBS

Rear: FORMULA MSL-148A - Front: FORMULA DC-611
Rear: 32h, sealed bearings, 12 x 148 mm, Shimano Microspline - Front: 32h, sealed bearings, 15 x 110 mm

SPOKES/NIPPLES

SAPIM Race
 2.0-1.8-2.0 mm, double butted, stainless, black

TYRES

Rear: MAXXIS Minion DHR II - Front: MAXXIS Assegai
Rear: 27.5" x 2.5", 3C MaxxTerra, Nexo + - Front: 27.5" x 2.5", 3C MaxxGrip, Nexo +

SEAT POST

RIDE ALPHA
34.9 mm, 400 mm on S/M, 450 mm on L/XL

SADDLE

FIZIK Terra Alpaca X5
145 mm width, S-alloy rails

WEIGHT

kg / lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED

No
